First Alert VISTAH Hybrid Series Hardwired Zone Expansion Module
Write a Review
First Alert
First Alert VISTAH Hybrid Series Hardwired Zone Expansion Module
First Alert
- SKU:
- VISTAHEXPHW
All Equipment is BRAND NEW, Factory Sealed with New Date Codes
All Products Ship Within 1 Business Day, Direct from Our Facility, With Tracking
FREE Standard Shipping Within the USA Included on All Products, Every Day
60-Day Hassle Free Money Back Guarantee Included with Your Purchase
Item Details
The VISTAHEXPHW hardwired zone expansion module allows you to add 8 additional hardwired zones (16 with zone doubling) per module to a VISTAH3 system. You can add up to 8 total modules increasing up to 64 total hardwired zones for those larger residential and commercial opportunities.
The module has a built-in tamper allowing detection and reporting if the front cover is removed and is supervised so if the wiring is cut a supervision alarm will result indicating the module may not be operational. The flexibility to mount the module on a surface wall or to a gang box depending on the installation environment and the terminal strips are removeable to give installers easier access to help making wiring easier.
| Approvals and Standards | NFPA-72 Compliant |
|---|---|
| Power Supply | Powered off the VISTAH3 controls power and battery backed up if panel losses AC |
| Operating Relative Humidity (Max) | 95% RH |
| Operating Relative Humidity (Min) | 0% RH |
| Ambient Operating Temperature (Max) | 122 °F, 50 °C |
| Ambient Operating Temperature (Min) | 32 °F, 0 °C |
